Material 1.0505

Fine grained structural steel

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

1.0505

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
request

Material Category: Fine grained structural steel

Chemical Composition

C % Si % Mn % P % S %   Al % Cr % Cu % Mo % N % Nb % Ni %
max 0,18 max 0,45 0,70 - 1,50 max 0,035 max  0,030   mind. 0,0200 max 0,30 max 0,20 max 0,08 max 0,020 max 0,030 max 0,30

Product Specifications

DIN SEW 310

Mechanical Properties

1.0505
normalgeglüht Streckgrenze (Re) Zugfestigkeit (Rm)  Bruchdehnung (A5,65) bei Temperatur
<= 16 mm >= 315 N/mm²     ~ 20 ° C
16 - 100 mm >= 315 N/mm²     ~ 20 ° C
35 - 50 mm >= 305 N/mm²
50 - 60 mm >= 295 N/mm²
60 - 70 mm >= 295 N/mm²
<= 70 mm   440 - 560 MPa ~ 23 %
>= 70 mm     ~ 23 %
70 - 85 mm >= 285 N/mm² 430 - 550 MPa
85 - 100 mm >= 275 N/mm² 420 - 540 MPa
100 - 125 mm >= 265 N/mm² 410 - 530 MPa
125 - 150 mm >= 255 N/mm² 400 - 520 MPa
150 - 250 mm >= 245 N/mm² 390 - 520 MPa   ~ 20 ° C
Faltversuch Probenlage
<= 250 mm längs
Kerbschlagarbeit KV (ISO-V/Charpy-V)
Abmessung Wert Probenlage bei Temperatur
10 - 150 mm ~ 40 Joule längs ~ -20 ° C
10 - 150 mm ~ 20 Joule quer ~ -20 ° C
10 - 150 mm ~ 43 Joule längs ~ -10 ° C
10 - 150 mm ~ 24 Joule quer ~ -10 ° C
10 - 150 mm ~ 47 Joule längs ~ 0 ° C
10 - 150 mm ~ 27 Joule quer ~ 0 ° C
10 - 150 mm ~ 51 Joule längs ~ 10 ° C
10 - 150 mm ~ 31 Joule quer ~ 10 ° C
10 - 150 mm ~ 55 Joule längs ~ 20 ° C
10 - 150 mm ~ 31 Joule quer ~ 20 ° C
Flachzeug
Faltversuch >= 600 mm quer
