Material 1.0506

Fine grained structural steel

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

1.0506

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
P315NH WStE315 request

Material Category: Fine grained structural steel

Chemical Composition

C % Si % Mn % P % S % Al % Cr % Cu % Mo % N % Nb % Ni %
max 0,18 max 0,45 0,70 - 1,50 max 0,035 max 0,030 mind 0,0200 max 0,30 max 0,20 max 0,08 max 0,020 max 0,030 max 0,30

Mechanical Properties

1.0506
normalgeglüht Streckgrenze (Re) Zugfestigkeit (Rm)  Bruchdehnung (A5,65)
<= 16 mm >= 315 N/mm²
16 - 35 mm >= 315 N/mm²
35 - 50 mm >= 305 N/mm²
50 - 60 mm >= 295 N/mm²
60 - 70 mm >= 295 N/mm²
>=70 mm     >= 23 %
<= 70 mm   440 - 560 N/mm² >= 23 %
70 - 85 mm >= 285 N/mm² 430 - 550 N/mm²
85 - 100 mm >= 275 N/mm² 420 - 540 N/mm²
100 - 125 mm >= 265 N/mm² 410 - 530 N/mm²
125 - 150 mm >= 255 N/mm² 400- 520 N/mm²
150 - 250 mm >= 245 N/mm² 390 - 520 N/mm²

Faltversuch Probenlage
<= 250 mm längs
normalgeglüht
Kerbschlagarbeit KV2 (ISO-V/Charpy-V)
Abmessung Wert Probenlage bei Temperatur
10 - 150 mm ~ 40 Joule längs ~ -20 ° C
10 - 150 mm ~ 20 Joule quer ~ -20 ° C
10 - 150 mm ~ 43 Joule längs ~ -10 ° C
10 - 150 mm ~ 24 Joule quer ~ -10 ° C
10 - 150 mm ~ 47 Joule längs ~ 0 ° C
10 - 150 mm ~ 27 Joule quer ~ 0 ° C
10 - 150 mm ~ 51 Joule längs ~ 10 ° C
10 - 150 mm ~ 31 Joule quer ~ 10 ° C
10 - 150 mm ~ 55 Joule längs ~ 20 ° C
10 - 150 mm ~ 31 Joule quer ~ 20 ° C

Faltversuch
>= 600 mm   quer
