Material 1.4028

Stainless steel

The material 1.4028 is a martensitic stainless steel.
This material is resistant in moderately aggressive environment.
If your product has a very smooth surface, you will achieve
the best corrosion resistance. Due to its increased carbon content
X30Cr13 is easy to harden. The hardenability, for example, is better than that of
than grade 1.4021, but you have to keep in mind that the corrosion resistance is somewhat lower.
To ensure supply for your projects, we have 1.4028 in round
and sawn flat dimensions in quenched and tempered condition in our stock.

In our sawing center we can produce your desired dimension in shortest time.
in a very short time.

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

1.4028

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
X30Cr13 AISI 420 AISI 420F UNS S42000 UNS S42020 SUS420J2 SUS420J2-CSP SUS420J2FB SUS420J2TKA request

Material Category: Stainless steel

Applications

Mechanical engineering
Pumps
Automotive industry

Weldability

1.4028 is difficult to weld

Chemical Composition

C % Si % Mn % P % S % Cr %
0,26 - 0,35 max 1,00 max 1,50 max 0,040 max 0,015 12,00 - 14,00



Mechanical Properties

geglüht Zugfestigkeit (Rm) Härte [HB 30] Probenlage
  <= 800 N/mm² <= 245 HB 30 längs
vergütet 0,2% Dehngrenze (Rp0,2) Zugfestigkeit (Rm) Bruchdehnung (A5, 65) Kerbschlagarbeit KV (ISO-V/Charpy-V)
<= 160 mm >= 650 N/mm² 800 - 1.000 N/mm² >= 10 % >= 15 Joule
angelassen bei 625 - 675 ° C
Zugfestigkeit (Rm) 850 - 1.000 N/mm²

Back to the overview and search.
