Material 2.4665

Nickellegierung

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

2.4665

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
AlloyX UNS N06002 request

Material Category: Nickellegierung

Chemical Composition

C % Si % Mn % P % S % Al % B % Co % Cr % Cu % Fe % Mo % Ni % W %
0,05 - 0,15 max 1,00 max 1,00 max 0,020 max 0,015 max 0,5000 max 0,0100 0,50 - 2,50 20,50 - 23,00 max 0,50 17,00 - 20,00 8,00 - 10,00 Rest 0,20 - 1,00



Product Specifications

DIN 17744 (09/2002)
DIN 17750 (09/2002)
DIN 17752 (09/2002)
DIN 17753 (09/2002)
DIN EN 10088-1 (12/2014)
DIN EN 10302 (06/2008)
- WL

Mechanical Properties

lösungsgeglüht
0,2% Dehngrenze (Rp0,2) Zugfestigkeit (Rm] Bruchdehnung (A5, 65) bei Temperatur
>= 270 N/mm² >= 690 N/mm² >= 30 % ~ 20 ° C
>= 260 N/mm²     ~ 100 ° C
>= 245 N/mm²     ~ 200 ° C
>= 230 N/mm²     ~ 300 ° C
>= 215 N/mm²     ~ 400 ° C
>= 200 N/mm²     ~ 500 ° C
>= 195 N/mm²     ~ 550 ° C
>= 190 N/mm²     ~ 600 ° C
>= 180 N/mm²     ~ 700 ° C
>= 165 N/mm²     ~ 800 ° C
>= 140 N/mm²     ~ 900 ° C
>= 80 N/mm²     ~ 1.000 ° C
