Material 2.4669

Nickellegierung

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

2.4669

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
AlloyX750 UNS N07750 request

Material Category: Nickellegierung

Chemical Composition

C % Si % Mn % P % S % Al % Co % Cr % Cu % Fe % Nb % Ni % Ti %
max  0,08 max 0,50 max 1,00 max 0,020 max 0,015 0,4000 - 1,0000 max 1,00 14,00 - 17,00 max 0,50 5,00 - 9,00 0,700 - 1,200 mind 70,00 2,25 - 2,75



Product Specifications

DIN EN 10088-1 (12/2014)
DIN EN 10269 (02/2014)
DIN EN 10302 (06/2008)
- WL

Mechanical Properties

ausgehärtet
0,2% Dehngrenze (Rp0,2) Zugfestigkeit (Rm) Bruchdehnung (A5, 65) bei Temperatur
>= 630 N/mm² >= 980 N/mm² >= 8 % ~ 20 ° C
>= 790 N/mm² >= 1.170 N/mm² >= 15 % ~ 20 ° C
>= 620 N/mm²     ~ 100 ° C
>= 610 N/mm²     ~ 200 ° C
>= 760 N/mm²     ~ 200 ° C
>= 601 N/mm²     ~ 300 ° C
>= 746 N/mm²     ~ 300 ° C
>= 592 N/mm²     ~ 400 ° C
>= 732 N/mm²     ~ 400 ° C
>= 582 N/mm²     ~ 500 ° C
>= 715 N/mm²     ~ 500 ° C
>= 573 N/mm²     ~ 600 ° C
>= 692 N/mm²     ~ 600 ° C
>= 642 N/mm²     ~ 700 ° C
>= 415 N/mm²     ~ 800 ° C
