Material 1.8515

Acero de nitruración

El material 1.8515 es un acero de nitruración. Los aceros de nitruración siempre se usan cuando se requiere una alta dureza superficial, una buena resistencia al desgaste y un área de núcleo dúctil. 31CrMo12 es ampliamente utilizado en ingeniería automotriz y general.

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

1.8515

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
request

Material Category: Acero de nitruración

Chemical Composition

C % Si % Mn % P % S % Cr % Mo %
0,28 - 0,35 max 0,40 0,40 - 0,70 max 0,025 max 0,035 2,80 - 3,30 0,30 - 0,50



Mechanical Properties

weichgeglüht Härte [HB] <= 248 HB
vergütet Streckgrenze (Re) Zugfestigkeit (Rm) Bruchdehnung (A5, 65) Kerbschlagarbeit KV
(ISO-V/Charpy-V)
16 - 40 mm >= 835 N/mm² 1.030 - 1.230 N/mm² >= 10 % >= 25 Joule
40 - 100 mm >= 785 N/mm² 980 - 1.180 N/mm² >= 11 % >= 30 Joule
100 - 160 mm >= 735 N/mm² 930 - 1.130 N/mm² >= 12 % >= 30 Joule
160 - 250 mm >= 675 N/mm² 880 - 1.080 N/mm² >= 12 % >= 30 Joule
Nitriert
weichgeglüht Härte [HV1] ~ 800 HV 1
